Simpson Light Tension Bridging

Mfr.: Simpson Strong-Tie
Item #: I093238
Mfr. #: LTB40
*
Pickup at Corona | Change Delivering to 92111 | Change

Price: $2.09
i h h

Description

The Simpson Strong-Tie LTB40 provides essential bracing between floor joists, significantly contributing to the overall structural strength of a floor system. Designed as a light tension-type bridging, it ensures joists remain securely in place, preventing rotation and effectively distributing loads across multiple joists. Its staggered nail pattern is engineered for versatility, accommodating 2x8 and 2x10 joists and offering multiple nailing options for a secure installation.
  • Light tension-type bridging
  • Staggered nail pattern
  • Corrosion resistant

Features

  • Keeps joists in place and prevents rotation.
  • Distributes loads over multiple joists.
  • Maximum nailing flexibility with up to six nail holes per end.
  • Galvanized (G90) for extra corrosion resistance.

Includes

  • 1 x 39 inch 22-Gauge Light Tension Bridging (LTB40)
Products specifications
length 39 inch
gauge 22
material 22 ga. (27 mil) steel
finish Galvanized (G90)
member size 2x8, 2x10
width 0.75 inch
depth 0.25 inch
fasteners required (2) 0.113 inch x 2 inch nails per end
packaging quantity 1
*
*
*
