Simpson Strong-Tie BA216 Top Flange Hanger 2x16

Mfr.: Simpson Strong-Tie
Item #: I091095
Mfr. #: BA216
*
Pickup at Corona | Change Delivering to 92111 | Change

Price: $34.98
i h h

Description

The Simpson Strong-Tie BA216 is a cost-effective one-piece top-flange hanger designed for engineered wood and solid sawn lumber applications. This hanger provides exceptional strength for medium to high load conditions, making it ideal for beam-to-beam and girder-to-girder connections. Its full-height joist flange captures the top chord of the joist to prevent rotation and eliminate the need for web stiffeners, ensuring superior structural integrity.
  • One-Piece Design
  • G90 Galvanized Finish

Features

  • Features Positive-Angle Nailing (PAN) for efficient installation and load transfer.
  • Unique two-level embossment provides added stiffness to the top flange.
  • Suitable for weld-on applications to steel headers.

Includes

  • (1) BA216 Top Flange Hanger
Products specifications
Model Number BA216
Joist Size 2x16
Material 12-Gauge Steel
Finish G90 Galvanized
Width 1-9/16 inch
Height 15 inch
Base 3 inch
Top Flange 2-1/2 inch
Header Fasteners (16) 0.162 inch x 3-1/2 inch Nails
Joist Fasteners (2) 0.148 inch x 1-1/2 inch Nails
*
*
*
