Simpson Strong-Tie BA312 Top Flange Hanger For 3X12

Mfr.: Simpson Strong-Tie
Item #: I091112
Mfr. #: BA312
*
Pickup at Corona | Change Delivering to 92111 | Change

Price: $30.81
i h h

Description

The Simpson Strong-Tie BA312 is a high-capacity top-flange hanger designed for 3x12 joists in both solid sawn lumber and engineered wood applications. It provides a cost-effective one-piece design that offers superior load-bearing strength for beam-to-beam and girder-to-girder connections. This hanger is engineered to ensure structural stability and long-lasting performance in demanding framing environments.
  • G90 Galvanized Finish
  • 12-Gauge Carbon Steel

Features

  • One-piece non-welded design for efficient structural support.
  • Full-height joist flange prevents rotation without web stiffeners.
  • Positive Angle Nailing (PAN) for optimized load distribution.
  • Two-level top flange embossment increases overall stiffness.

Includes

  • (1) BA312 Top Flange Hanger
Products specifications
Model Number BA312
Joist Size 3x12
Material Carbon Steel
Finish G90 Galvanized
Thickness 12 Gauge
Hanger Width 2-9/16 inch
Hanger Height 11-1/8 inch
Top Flange Length 2-1/2 inch
Header Fasteners (16) 0.162 x 3-1/2 inch Nails
Joist Fasteners (2) 0.148 x 1-1/2 inch Nails
*
*
*
