    12 in. Double-Bevel Sliding Compound Miter Saw

    Mfr.: Dewalt
    Item #: I038095
    Mfr. #: DWS780
    *
    Pickup at Corona | Change Delivering to 92111 | Change

    Price: $765.82
    i h h

    Description

    Conquer demanding miter saw tasks with this 12-inch Double-Bevel Sliding Compound Miter Saw. Featuring a robust 15 Amp motor and the integrated XPS crosscut positioning system for precise, adjustment-free cut line guidance, this tool is engineered with a resilient stainless-steel miter detent plate and cam lock for unparalleled durability and accuracy.
    • Dimensions - 35cm x 45cm x 25cm
    • The generously sized bevel scale ensures effortless and precise bevel angle adjustments.
    • Its compact and lightweight construction (58 lbs.) makes transport and storage incredibly convenient.

    Features

    • The cam lock miter handle, complete with a detent override, allows for swift and accurate miter angle setting.
    • Dual horizontal steel rails, equipped with a cutting-edge clamping mechanism and linear ball bearings, deliver a saw that is both accurate, durable, and remarkably compact.
    • An innovative gearbox and belt-drive system enhances its vertical cutting capabilities.
    • Built for heavy-duty performance, the 1100 Watt motor is designed to tackle the toughest jobs.
    • The integrated CUTLINE Blade Positioning System offers adjustment-free cut line indication, significantly improving accuracy and visibility.
    • Experience sustained power and durability with the formidable 15 Amp, 3,800 rpm motor.
    • An exceptionally efficient dust collection system captures over 75% of generated dust for a cleaner workspace.
    • Tall sliding fences expertly support nested crown molding up to 7-1/2 inches and vertical base molding up to 6-3/4 inches against the fence, while easily sliding away for bevel cuts.
    • The exclusive back fence design enables cuts of up to 2x14 dimensional lumber at 90 and 2x10 at 45.
    • Boost your productivity and ensure cutting precision with the adjustable stainless-steel miter detent plate featuring 10 positive stops.
    • Achieve greater capacity with miters extending 60 to the right and 50 to the left.

    Includes

    • (1) Blade wrench
    • (1) Dust bag
    • (1) Vertical material clamp
    • (1) 12 in. Carbide blade
    • (1) 12 in. Miter saw
    Products specifications
    Blade Bore (mm) 30
    Blade Diameter (in) 12
    Blade Diameter (mm) 305
    Are Accessories Included Yes
    Bevel Capacity (deg) 49°/49°
    Blade Bore (in) 1.18
    Possible Mitre Angles (deg) 50°/60°
    Packaging Carton
    Number Of Pieces 5
    Power Input (W) 1675
    Product Depth (in) 32.33
    Power Source Corded
    Power Output (W) 960
    No Load Speed (RPM) 3800
    Max. Cutting Capacity (9045) (mm) 268 x 63
    Max. Cutting Capacity (4590) (mm) 211 x 112
    Max. Cutting Capacity (4590) (in) 4x10
    Max. Cutting Capacity (9090) (in) 2x14
    Max. Depth of Cut (mm) 170
    Max. Depth of Cut (in) 6.69
    Max. Cutting Capacity (9090) (mm) 303 x 110
    Product Depth (mm) 470
    Saw Blade Thickness (mm) 2.6
    Saw Blade Thickness (in) 0.1
    Product Width (in) 23
    Sound Power (dB(A)) 100
    Weight (Including Battery) (lbs) 56
    Uncertainty K1 (Vibration) 1.5 m/s2
    Sound Pressure (dB(A)) 93
    Product Weight (oz) 896
    Product Length (in) 32.33
    Product Height (mm) 396
    Product Height (in) 19.5
    Product Length (mm) 770
    Product Weight (lbs) 56
    Product Weight (Kg) 25.5
    Product Weight (g) 25500
    Cutting Capacity (in) 14
    Disc Diameter (in) 12
    Disc Diameter (mm) 305
    Color Silver, Yellow
    CutterSaw Wheel Diameter (in) 12
    Cutter Saw Wheel Diameter (mm) 305
    Max. Cutting Capacity (4545) (in) 2x10
    Max. Cutting Capacity (4545) (mm) 211 x 63
    Blade Speed (rpm) 3800
    Has Dust Extraction Yes
    Has LED Light No
    Has Supplied in Storage Case Indicator No
    *
    *
    *
