Ertec Curb Inlet Guard - 8-inch Height

Mfr.: Ertec Pro Wattle
Item #: I090699
Mfr. #: CIG88
*
Pickup at San Diego | Change Delivering to 92111 | Change

Price: $146.20
i h h

Description

Curb Inlet Guard (CIG) is a patented, low-cost system engineered to reduce sedimentation into curb drain inlets while balancing the critical tradeoff between street safety and sediment capture. The units are constructed from durable HDPE and feature integrated brackets to prevent collapse into the storm drain. Designed for longevity and reuse, the system includes an integrated filter with a vertical height of 2 inches to allow water to bypass during high-flow events.

Features

  • Modular design allows segments to overlap and fit any curb opening length
  • Constructed from durable HDPE with built-in stability brackets
  • Integrated 2-inch filter height and matrix bypass for high-flow conditions
  • UV stable and designed for a functional life of at least 4 years
  • Easy to install, clean, and reuse across multiple projects
Products specifications
Module Weight 3.0 lbs
Functional Life 4 years (min)
Module Height 8.0 inches (min)
Module Length 6.25 ft
Opening Size Protected 5 ft
Filter Freeboard Height 2.0 inches
Integrated Brackets Yes
Reusable Yes
Filter AOS 425 microns (min)
Tensile Yield (ASTM D-638) 1800 - 2800 lb/in2
Ultimate Tensile Strength (ASTM D-638) 2000 - 2800 lb/in2
Service Temperature -30 to 160 deg F
Filter Flow Rate (ASTM D-4491) 145 gpm/ft2 (min)
Bypass for High Flow Yes
Seals to Pavement Yes
*
*
*
