Gr8 Guard 36 inch x 24 inch

Item #: I023538
Mfr. #: GG 36x24
*
Pickup at San Diego | Change Delivering to 92111 | Change

Price: $117.88
i h h

Description

The GR8 Guard is a patent-pending, low-profile drainage inlet protection system designed to effectively filter sediment and debris from grated storm drain inlets in paved areas. Its unique design allows water to rise at least 1.5 inches before reaching the filter core, encouraging heavier particles to settle before filtration. The system is engineered for high-flow performance and includes a built-in bypass to minimize the risk of street flooding during extreme weather events.

  • Easy Installation: Can be installed in minutes using wire ties without the need to remove heavy grates, reducing the risk of installer injury.
  • Durable & Reusable: Constructed from UV-stable materials designed to withstand traffic run-overs and harsh environmental conditions for a functional life of 4+ years.
  • Maintenance: The above-ground design allows for easy visual inspection and rapid cleaning without specialized equipment.
  • Environmental Impact: 100% recyclable and reusable across multiple project phases or sites.
Products specifications
Ultimate Tensile 2000 - 2800 psi
Tensile Yield 1800 - 2800 psi
Functional Life 4 years (minimum)
Filter Flow Rate 145 gpm/ft2
Reusable Yes
Product Height 2 inches
Service Temp -30 to 160 degF
Filter AOS 425 microns
Fits Grate Size Up to 36 inch x 24 inch
Module Weight 0.5 lbs/sq. ft.
*
*
*
