Greenstreak Model 581 PVC Retrofit System, priced per 10 ft section

Mfr.: Greenstreak -Sika
Item #: I101494
Mfr. #: 705814
*
Pickup at San Diego | Change Delivering to 92111 | Change

Digital Downloads
Price: $685.51
i h h

Description

The Sika Greenstreak Model 581 PVC Retrofit System is a lightweight surface-mounted waterstop used to seal construction joints where new concrete meets an existing structure, and is also suitable for working joints. The 10 ft PVC waterstop strip is mechanically anchored to the existing concrete using stainless steel batten bars and anchor bolts, with structural epoxy gel applied to reinforce adhesion. Priced per 10 ft section.
  • Each 10 foot piece of 581 waterstop requires (419358): | (419289) 497 Stainless Steel Batten Bar: 1 Piece | (419223) 609 Stainless Steel Anchor Bolts:: 1 Bag | 7300 Epoxy: 30-35 Feet Coverage per Gallon - Sold separately
  • Lightweight retrofit waterstop for new-to-existing concrete joints
  • Suitable for working (moving) joints
  • Raised center bulb profile to accommodate joint movement
  • Installs with stainless steel batten bars, anchor bolts and structural epoxy gel

Features

  • Each 10 foot piece of 581 waterstop requires (419358): | (419289) 497 Stainless Steel Batten Bar: 1 Piece | (419223) 609 Stainless Steel Anchor Bolts:: 1 Bag | 7300 Epoxy: 30-35 Feet Coverage per Gallon - Sold separately
  • 3-1/8 in. wide x 3-11/16 in. high PVC retrofit profile
  • Supplied in 10 ft sections, priced per 10 ft section
  • Lightweight, approximately 1.51 lb/ft
  • Temperature resistance -35 F to 170 F (-37 C to 77 C)
  • Low water absorption rate, 0.15% max
  • System components: waterstop profile, stainless steel batten bars, anchor bolts

Specifications


Model581TypePVC Retrofit System
Width3 1/8 inchHeight3 11/16 inch
Section length10 ftPricingPer 10 ft section
MaterialPVCWeight1.51 lb/ft
Joint typeNew-to-existing / working jointTemperature range-35 F to 170 F (-37 C to 77 C)
Water absorption0.15% maxInstallationStainless steel batten bars, anchor bolts, structural epoxy gel
*
*
*
