Greenstreak Model 646 PVC Waterstop 9"x3/8" FR, 50 ft roll, priced per foot

Mfr.: Greenstreak -Sika
Item #: I101478
Mfr. #: 419383
*
Pickup at San Diego | Change Delivering to 92111 | Change

Digital Downloads
Price: $17.98
i h h

Description

Greenstreak Model 646 is a 9 in. flexible PVC flat ribbed waterstop used to form a watertight diaphragm at non-moving construction joints in cast-in-place concrete. When embedded across the joint it prevents the passage of liquid, and its ribbed profile mechanically locks the waterstop into the concrete on both sides. Suitable for potable water contact per NSF/ANSI Standard 61.
  • Flat ribbed profile enhances mechanical bond within poured concrete
  • Optimized for construction joint water sealing
  • Durable PVC material provides resistance to water, chemicals, and aging
  • Used in slabs, walls, and structures requiring dependable watertight joints
  • Flexible PVC for non-moving construction joints
  • Flat ribbed profile keys into concrete to resist hydrostatic pull-out
  • NSF/ANSI 61 certified for potable water contact
  • Complies with U.S. Army Corps of Engineers spec CRD-C 572-74
  • Heat-weldable for continuous splices and field fabrication

Features

  • Flat ribbed profile enhances mechanical bond within poured concrete
  • Optimized for construction joint water sealing
  • Durable PVC material provides resistance to water, chemicals, and aging
  • Used in slabs, walls, and structures requiring dependable watertight joints
  • Flexible PVC for non-moving construction joints
  • Flat ribbed profile keys into concrete to resist hydrostatic pull-out
  • NSF/ANSI 61 certified for potable water contact
  • Complies with U.S. Army Corps of Engineers spec CRD-C 572-74
  • Heat-weldable for continuous splices and field fabrication
  • Model: 646
  • Size: 9 in. x 3/8 in.
  • Profile: Flat Ribbed (FR)
  • Roll length: 50 ft
  • Material: PVC
  • Joint type: Non-moving / construction joint
  • Priced per foot

Specifications


Model646Size9 inch x 3/8 inch
ProfileFlat Ribbed (FR)Roll length50 ft
MaterialPVCJoint typeNon-moving / construction joint
Shore A Hardness79 +/- 3 (ASTM D2240)Tensile Strength2000 psi min (ASTM D638)
StandardsNSF/ANSI 61; CRD-C 572-74PricingPer foot
*
*
*
