  • Greenstreak Model 782 PVC Waterstop 6"x3/16" FR, 100 ft roll, priced per foot

Greenstreak Model 782 PVC Waterstop 6"x3/16" FR, 100 ft roll, priced per foot

Mfr.: Greenstreak -Sika
Item #: I101490
Mfr. #: 419594
*
Pickup at San Diego | Change Delivering to 92111 | Change

Digital Downloads
Price: $6.40
i h h

Description

Greenstreak Model 782 is a flexible PVC waterstop with a 6 in. wide, 3/16 in. thick flat ribbed (FR) profile for use in concrete construction and expansion joints. The ribbed flanges anchor into the concrete to form a continuous watertight diaphragm that prevents passage of liquid through the joint. Supplied in 100 ft rolls and priced per foot.
  • Flat ribbed profile enhances mechanical bond within poured concrete
  • Optimized for construction joint water sealing
  • Durable PVC material provides resistance to water, chemicals, and aging
  • Used in slabs, walls, and structures requiring dependable watertight joints
  • Flat ribbed flanges provide mechanical anchorage in concrete
  • Wide 6 in. profile for increased water path and sealing
  • Forms a continuous watertight diaphragm across the joint
  • Suitable for potable water contact per NSF/ANSI Standard 61

Features

  • Flat ribbed profile enhances mechanical bond within poured concrete
  • Optimized for construction joint water sealing
  • Durable PVC material provides resistance to water, chemicals, and aging
  • Used in slabs, walls, and structures requiring dependable watertight joints
  • 6 in. wide x 3/16 in. thick flat ribbed profile
  • Supplied in 100 ft rolls, priced per foot
  • Approximate weight 0.84 lb/ft (1.25 kg/m)
  • Head pressure rating approximately 75 ft (224 kPa)
  • Meets Army Corps of Engineers Specification CRD-C 572-74; passes brittleness at -35 F
  • Applications: construction and expansion joints in water-retaining structures

Specifications


Model782ProfileFlat ribbed (FR)
Width6 inchThickness3/16 inch
Roll length100 ftPricingPer foot
MaterialFlexible PVCJoint typeConstruction/expansion joint
Weight0.84 lb/ft (1.25 kg/m)Head pressure rating75 ft (224 kPa)
StandardsNSF/ANSI 61, CRD-C 572-74
*
*
*
