Klein Tools CL445 HVAC Clamp Meter

Mfr.: Klein Tools
Item #: I095300
Mfr. #: CL445
*
Pickup at Corona | Change Delivering to 92111 | Change

Price: $172.63
i h h

Description

The CL445 is an automatically ranging true RMS digital clamp meter designed for HVAC applications. It measures AC current, inrush current, voltage, temperature, and various electrical parameters with high accuracy.
  • Automatically ranging true RMS for accuracy
  • Simultaneous voltage and current display
  • Built-in worklight and non-contact voltage tester
  • K-Type thermocouple for temperature measurement
  • CAT IV 600V, CAT III 750V safety rating

Features

  • Measures AC current up to 600A and inrush current
  • Tests voltage, resistance, continuity, frequency, capacitance
  • Temperature range from -148F to 1832F
  • Backlit LCD with dual V + A function
  • Includes test leads, thermocouple, storage pouch, batteries

Includes

  • Clamp meter
  • Right-angle input test leads
  • Push-on alligator clips
  • K-Type thermocouple
  • Storage pouch
  • Instruction manual
  • 3 x AAA batteries

Specifications

TypeHVAC TRMS Clamp MeterJaw Size1.25 inch (3.2 cm)
Display6000 Count LCDAC Voltage750V
DC Voltage600VCurrent600A AC
DC Micro-Amp600uACapacitance6.000mF
Resistance60MFrequency60 kHz
Temperature Range-148 deg to 1832 degFDrop Protection6.6 ft (2 m)
Auto-Power OffYesSafety RatingCAT IV 600V, CAT III 750V
Overall Length9.24 inch (23.5 cm)Overall Height1.59 inch (4 cm)
Overall Width3.77 inch (9.6 cm)Batteries3 x AAA
*
*
*
