Minnich FS-8102 Flex-Shaft Core & Casing

Mfr.: Minnich Manufacturing
Item #: I070762
Mfr. #: 0A8163-00000
*
Pickup at Corona | Change Delivering to 92111 | Change

Price: $233.64
i h h

Description

The Minnich FS-8102 is a heavy-duty flex-shaft core and casing assembly designed for high-performance concrete consolidation. Featuring a 1-3/16-inch diameter and a 2-foot length, this component is engineered to provide maximum durability in demanding job site conditions. Its robust construction ensures efficient power transfer from the motor to the vibrator head, helping operators achieve smooth and consistent concrete finishes.
  • Heavy-Duty Steel Reinforced Casing
  • Reversible Core Design

Features

  • Reversible core allows for an extended lifespan by doubling the usable wear surface.
  • Integrated core strain relief provides extra protection against kinking and mechanical stress.
  • Coarse thread design on both the core and casing prevents cross-threading during assembly and maintenance.
  • Steel reinforcement within the casing provides superior abrasion resistance and long-term reliability.

Includes

  • 1-3/16' x 2' Casing
  • Internal Reversible Core
Products specifications
Material Steel Reinforced Rubber / Fusion Casing
Shaft Length 2.0 feet
Casing Diameter (OD) 1-3/16 inch (1.188 inch)
Thread Type Coarse Thread
Part Number 0A8163-00000
Model FS-8102
Compatibility Minnich Stinger and CSV Series Electric Motors
*
*
*
