Mirafi 500X Woven Filter Fabric - 12.5' x 432' (5400 sf)

Mfr.: Solmax - Mirafi
Item #: I024014
Mfr. #: 500X/12.5/432
*
Pickup at Corona | Change Delivering to 92111 | Change

Digital Downloads
Price: $517.38
i h h

Description

UV-stabilized, woven filtration geotextile manufactured with unique monofilament yarns for use in filtration and drainage applications.
  • UV-stabilized woven monofilament geotextile
  • Designed for filtration and drainage applications

Features

  • High seam efficiency
  • UV-stabilized for durability
  • Unique monofilament yarn construction
  • Suitable for filtration and drainage

Specifications


Product TypeWoven Filter FabricSeriesMIRAFI 500X
MaterialMonofilament yarnsApplicationFiltration and drainage
Products specifications
Apparent Opening Size #30 sieve
Application Soil Reinforcement/Separation
CBR Puncture Strength 500 lb
Certifications AASHTO M288 Compliant
Country of Origin USA (subject to change)
Coverage Area 5400 sf
Geotextile Type Woven
Grab Tensile Strength 200 lb
Permittivity 0.05 sec⁻¹
Polymer Type Polypropylene
Roll Length 432 ft
Roll Width 12.5 ft
Series 500X
UV Resistance 70% @ 500 hr
Water Flow Rate 4 gpm/ft²
Wide Width Tensile Strength 200 lb
*
*
*
