Mirafi HP370 Woven Geotextile - 15' x 300' (4500 sf)

Mfr.: Solmax - Mirafi
Item #: I026032
Mfr. #: HP370/15/300
*
Pickup at Corona | Change Delivering to 92111 | Change

Digital Downloads
Price: $1,593.00
i h h

Description

MIRAFI HP370 is a woven geotextile designed for soil stabilization and layer separation, providing strength and durability for roads, railways, and embankment construction.
  • Excellent separation with controlled filtration and drainage
  • Resists damage from moderate to severe installation stresses
  • Available in multiple roll sizes
  • Panels can be sewn together for cross-roll direction strength

Features

  • Woven geotextile for reinforcement and separation
  • Provides strength and durability for various applications
  • Controlled filtration and drainage properties
  • Resistant to installation stresses
  • Customizable roll sizes and seaming options

Includes

  • 1 roll of MIRAFI HP370 (15' x 300')

Specifications


Product TypeWoven GeotextileRoll Size15 x 300 (4500 sf)
SeriesHP-SeriesApplicationsSoil stabilization, layer separation, road and rai
Products specifications
Apparent Opening Size #40 sieve
Application Soil Separation/Filtration/Drainage
CBR Puncture Strength 950 lb
Certifications AASHTO M288 Compliant
Country of Origin USA (subject to change)
Coverage Area 4500 sf
Geotextile Type Woven
Grab Tensile Strength 330 lb
Mass per Unit Area 8.4 oz/yd²
Permittivity 0.5 sec⁻¹
Polymer Type Polypropylene
Roll Length 300 ft
Roll Width 15 ft
Series HP370
UV Resistance 70% @ 500 hr
Water Flow Rate 40 gpm/ft²
Wide Width Tensile Strength 2640 lb/ft (MD) x 2460 lb/ft (CD)
*
*
*
