Mirafi HP570 Woven Geotextile - 15' x 300' (4500 sf)

Mfr.: Solmax - Mirafi
Item #: I012992
Mfr. #: HP570/15/300
*
Pickup at Corona | Change Delivering to 92111 | Change

Digital Downloads
Price: $1,919.77
i h h

Description

MIRAFI HP570 is a woven geotextile designed for soil stabilization and separation in roads, railways, and embankments. It provides excellent separation with controlled filtration and drainage, resisting moderate to severe installation stresses.
  • Proven solution for soil and aggregate reinforcement
  • Resists damage from moderate to severe stresses during installation
  • Available in multiple roll sizes
  • Panels can be sewn together for cross-roll direction strength

Features

  • Provides excellent separation factors with controlled filtration and drainage
  • Resists damage from moderate to severe stresses during installation
  • Available in multiple roll sizes to fit a range of project requirements
  • Panels can be sewn together in the factory or field, providing cross-roll direction strength

Specifications


Product TypeWoven GeotextileSeriesHP-Series
ModelHP570Roll Size15 x 300 (4500 sf)
ApplicationSoil stabilization and separation
Products specifications
Apparent Opening Size #40 sieve, #40 sieve, #40 sieve
Application Soil Reinforcement/Separation, Soil Reinforcement/Separation, Soil Reinforcement/Separation
CBR Puncture Strength 1500 lb, 1500 lb, 1500 lb
Certifications AASHTO M288 Compliant, AASHTO M288 Compliant, AASHTO M288 Compliant
Country of Origin USA (subject to change), USA (subject to change), USA (subject to change)
Coverage Area 4500 sf, 4500 sf, 4500 sf
Geotextile Type Woven, Woven, Woven
Grab Tensile Strength 525 lb, 525 lb, 525 lb
Mass per Unit Area 10.4 oz/yd², 10.4 oz/yd², 10.4 oz/yd²
Permittivity 0.5 sec⁻¹, 0.5 sec⁻¹, 0.5 sec⁻¹
Polymer Type Polypropylene, Polypropylene, Polypropylene
Roll Length 300 ft, 300 ft, 300 ft
Roll Width 15 ft, 15 ft, 15 ft
Series HP570, HP570, HP570
UV Resistance 70% @ 500 hr, 70% @ 500 hr, 70% @ 500 hr
Water Flow Rate 40 gpm/ft², 40 gpm/ft², 40 gpm/ft²
Wide Width Tensile Strength 4800 lb/ft, 4800 lb/ft, 4800 lb/ft
*
*
*
