Mirafi Miragrid 24XT Geogrid - 12' x 200' (2400 sf)

Mfr.: Solmax - Mirafi
Item #: I056452
Mfr. #: 24XT/12/200
*
Pickup at San Diego | Change Delivering to 90001 | Change

Digital Downloads
Price: $2,400.61
i h h

Description

MIRAGRID XT geogrids are the premier solution for soil reinforcement in Mechanically Stabilized Earth (MSE) Walls and Reinforced Soil Slope (RSS) structures. The 24XT variant is designed for high-performance reinforcement applications.
  • Geosynthetic solutions for soil reinforcement
  • Designed for MSE walls and RSS structures

Features

  • High tensile strength for soil reinforcement
  • Durable polymer construction
  • Resistant to installation damage
  • Easy to handle and install

Specifications


Product TypeGeogridSeriesMIRAGRID XT-Series
Model24XTApplicationSoil reinforcement in MSE walls and RSS structures
Products specifications
Application Soil Reinforcement
Certifications ASTM D6637 Compliant
Color Black
Country of Origin USA (subject to change)
Coverage Area 2400 sf
Geotextile Type Geogrid
Polymer Type Polyester
Roll Length 200 ft
Roll Width 12 ft
Series Miragrid 24XT
UV Resistance 70% retained @ 500 hr
Wide Width Tensile Strength 19180 lb/ft (MD)
*
*
*
