Simpson 4X4 Elevated Post Base 14-Gauge

Mfr.: Simpson Strong-Tie
Item #: I090999
Mfr. #: EPB44A
*
Pickup at Corona | Change Delivering to 92111 | Change

Price: $17.23
i h h

Description

The Simpson Strong-Tie EPB44A is a 14-gauge elevated post base designed to provide a secure connection between wood posts and cast-in-place concrete. This essential connector features a built-in standoff that keeps the post base elevated, effectively preventing wood rot by eliminating contact with moisture. It is an ideal solution for outdoor projects such as decks, patio covers, and other top-supported structures. Crafted from durable steel with a G90 galvanized coating, the EPB44A ensures long-lasting stability and code-compliant performance in various construction environments.
  • Cast-in-place installation
  • 2-inch standoff height
  • Galvanized G90 finish

Features

  • Provides the code-required 1-inch standoff to prevent rot at the post end.
  • Allows up to 2 inches of clearance for moisture barriers and surface finishes.
  • Designed specifically for 4x4 nominal wood posts.
  • Requires (8) 0.162 inch x 3-1/2 inch nails for secure attachment.

Includes

  • Simpson Strong-Tie EPB44A Elevated Post Base
Products specifications
Model Number EPB44A
Material 14-Gauge Steel
Finish Galvanized (G90)
Post Size 4x4
Standoff Height 2 inches
Required Fasteners (8) 0.162 inch x 3-1/2 inch Nails
Installation Type Cast-in-Place
Code Compliance Meets 1 inch Standoff Requirement
*
*
*
