Simpson 5In Reinforcing Angle Zmax

Mfr.: Simpson Strong-Tie
Item #: I093199
Mfr. #: L50Z
*
Pickup at Corona | Change Delivering to 92111 | Change

Price: $3.73
i h h

Description

The Simpson Strong-Tie L50Z is a heavy-duty, L-shaped reinforcing angle designed to strengthen corners, braces, and splices in both wood and cold-formed steel applications. Made from 16-gauge alloy steel with a G90 ZMAX zinc coating, it offers exceptional corrosion resistance, making it ideal for outdoor projects or moist environments. Its pre-defined fastener locations and staggered nail pattern help prevent wood splitting and ensure consistent, straight corners. This versatile connector provides load-rated performance for decks, joists, and post-to-beam connections, serving as an engineered alternative to field-fabricated angles.
  • ZMAX G90 zinc-galvanized finish for superior corrosion protection.
  • 16-gauge alloy steel construction for structural strength.

Features

  • Staggered nail pattern reduces the risk of wood splitting.
  • Load-rated for use with wood and cold-formed steel.
  • Wider leg design for optimal nailing and accurate load transfer.
  • Engineered and tested with tabulated load values.

Includes

  • Sold individually.
Products specifications
Product Code L50Z
Length 5 inch
Material 16-Gauge Alloy Steel
Coating ZMAX
Gauge 16
Fastener compatibility Hot-dip galvanized nails
For Treated Lumber Yes
*
*
*
