Simpson 6X End Post Cap Zmax

Mfr.: Simpson Strong-Tie
Item #: I092820
Mfr. #: EPC6Z
*
Pickup at Corona | Change Delivering to 92111 | Change

Price: $58.30
i h h

Description

The Simpson Strong-Tie EPC6Z is engineered as a fast and easy solution for post-to-beam end connections. Crafted from durable, heavy-gauge steel with a ZMAX finish, it offers excellent corrosion resistance for various environments. Its design accommodates multiple beam sizes with in-line flanges, providing a custom connection and enhanced structural stability for decks and other construction projects. This post cap is ideal for applications requiring increased uplift loads, such as those subjected to earthquake or wind forces.
  • Heavy-gauge steel construction
  • ZMAX coating for corrosion resistance

Features

  • Designed for 6x posts and beams
  • In-line flanges accommodate multiple beam sizes
  • Certified welds for increased strength
  • Enhanced uplift loads for wind or seismic conditions

Includes

  • Not explicitly listed, but installation requires 10d (0.148 inch x 3 inch) common nails or Strong-Drive SD Connector screws.
Products specifications
material Steel
finish ZMAX
lumber_size 6x posts and beams
gauge 16 gauge
width 5 1/2 in
weight_capacity 1230 lb Lateral / 1435 lb Uplift
height 6.5 in
weight 0.9 lb
*
*
*
