  • Simpson PPHD Sheathing-to-CFS Screw (Collated) - #8 x 1-15/16" T25, Yellow Zinc - 2000/box

Simpson PPHD Sheathing-to-CFS Screw (Collated) - #8 x 1-15/16" T25, Yellow Zinc - 2000/box

Mfr.: Simpson Strong-Tie
Item #: I100437
Mfr. #: PPHD11516S0817
*
Pickup at Corona | Change Delivering to 92111 | Change

Price: $301.07
i h h
WARNING: California Prop 65 : Cancer and Reproductive Harm - http://www.P65Warnings.ca.gov

Description

PPHD screws are designed for use in dry service, low-corrosion environments and some fire-rated sheathing. They are compatible with Quik Drive auto-feed screw driving systems.
  • #8 x 1-15/16 inch size
  • T25 6-lobe recess
  • Yellow zinc coating
  • 2000-count package
  • Buttress threads

Features

  • Designed for sheathing, drywall, subfloor to CFS
  • Maximum thickness two layers of 18 ga. (0.100 inch total)
  • Recommended wood panel sheathing thickness: 7/8 inch
  • Compatible with Quik Drive PRO200SG2, PRO250G2, PRO300SG2
  • Pilot point for easy starting

Includes

  • 2000 screws
  • (2) T25 6-lobe driver bits (replacement bit model QRTX25-1.5)

Specifications


Model No.PPHD11516S0817CoatingMaterialYellow-Zinc Coated
Screw Size#8Length (in.)1 15/16
Head Diameter (in.)0.323Drive TypeT25 6-Lobe
Head TypeFlat HeadThread TypeButtress Threads
TPI17Max. Grip Length (in.)1.034
Point TypePilot PointPoint Size5
Compatible ToolsQuik Drive PRO200SG2, Quik Drive PRO250G2, QuikPackaging Qty.2000
*
*
*
