Simpson Purlin Anchor 23-3/4In

Mfr.: Simpson Strong-Tie
Item #: I093316
Mfr. #: PA23
*
Pickup at Corona | Change Delivering to 92111 | Change

Price: $13.31
i h h

Description

The Simpson Strong-Tie PA23 Purlin Anchor is engineered for strength and reliability, making it an essential component for wood-to-concrete and concrete-block connections. It is designed to meet stringent building code requirements, ensuring secure and durable attachments for structural integrity. This anchor features a dual-embedment line for easy installation in various applications, providing flexibility and peace of mind.
  • Robust Construction
  • Versatile Installation

Features

  • Dual-embedment design for installation in concrete or concrete block.
  • Galvanized finish for corrosion resistance.
  • Compatible with treated lumber.
  • Made from durable carbon steel.
  • Strap can be bent one full cycle for flexibility.
  • Minimum embedment line indicators for concrete and masonry installations.
  • Nailing pattern optimized for narrow face of nominal 2x or 3x wood members.
  • Low design profile minimizes visibility.

Includes

  • 1x Purlin Anchor
Products specifications
Length 23-3/4 inch
Material Carbon Steel / Galvanized Steel
Gauge 12 ga
Width 2-1/16 inch
For Treated Lumber Yes
Fasteners Masonry:14-16d; Concrete:18-16d
*
*
*
