Simpson PAB 5/8" x 36" HDG Pre-Assembled Anchor Bolt w/ Washer

Mfr.: Simpson Strong-Tie
Item #: I093353
Mfr. #: PAB5-36-HDG
*
Pickup at Corona | Change Delivering to 92111 | Change

Price: $61.24
i h h

Description

Pre-assembled anchor bolt with plate washer and hex nuts, ideal for high-tension-load applications like rod systems and shearwalls. Hot-dip galvanized finish for corrosion resistance.
  • 5/8 inch diameter, 36 inch length
  • Hot-dip galvanized (HDG) finish
  • Pre-assembled with plate washer and hex nuts
  • Head stamp for easy identification

Features

  • Available in diameters from 1/2 inch to 1-1/4 inch and lengths from 12 inch to 36 inch in 6 inch increments
  • Available in standard and high-strength steel
  • Head stamp contains No Equal sign, diameter designation, and 'H' on high-strength rods
  • Material: Standard Steel - ASTM F1554 Grade 36, A36 or A307; Fu = 58 ksi
  • Finish: HDG

Includes

  • Pre-assembled anchor bolt with plate washer and two hex nuts

Specifications


Diameter5/8 inchLength36 inch
FinishHDGMaterialASTM F1554 Grade 36, A36 or A307
Tensile Strength58 ksiWasher TypePlate washer
Nut TypeHex nutsHead StampNo Equal, diameter, H if high-strength
*
*
*
