Simpson Strong-Tie Triple 2X12 Top Flange Face Mount Hanger

Mfr.: Simpson Strong-Tie
Item #: I091460
Mfr. #: HU212-3TF
*
Pickup at Corona | Change Delivering to 92111 | Change

Price: $99.23
i h h

Description

The Simpson Strong-Tie HU212-3TF is a heavy-duty top-flange joist hanger designed for high-capacity applications requiring superior strength and structural stability. This hybrid hanger integrates the benefits of both face-mount and top-mount designs to provide a robust connection for triple 2x12 joists. It is engineered for long-term performance in residential and commercial framing projects, including floor systems and roof rafter connections.
  • G90 Galvanized Finish
  • 12-Gauge Heavy-Duty Steel

Features

  • Hybrid design combines face-mount and top-mount advantages for versatile installation.
  • Capable of being skewed or sloped up to 45 for complex framing requirements.
  • Engineered with face-nailing for maximum attachment security to the carrying member.

Includes

  • (1) Triple 2x12 Top Flange Joist Hanger
Products specifications
Model No HU212-3TF
Series HUTF
Joist Size Triple 2x12
Material 12-Gauge Carbon Steel
Finish G90 Galvanized
Width 4-11/16 inch
Height 11 inch
Top Flange Width 2-1/2 inch
Face Fasteners (16) 0.162 inch x 3-1/2 inch Nails
Joist Fasteners (6) 0.162 inch x 3-1/2 inch Nails
*
*
*
