Simpson 24" x 108" Strong-Wall High-Strength Wood Shearwall

Mfr.: Simpson Strong-Tie
Item #: I094142
Mfr. #: WSWH24X9
*
Pickup at Corona | Change Delivering to 92111 | Change

Price: $1,566.99
i h h

Description

The Strong-Wall WSWH high-strength wood shearwall is a prefabricated engineered wood panel that helps structures resist forces resulting from high wind and earthquakes. Combining design flexibility with performance, this code-listed shearwall is field adjustable with the ability to be trimmed and drilled onsite and can be customized to accommodate varying heights or rake walls. The WSWH features patented wood fuse technology that provides predictable behavior and delivers superior strength, stiffness, ductility and design values.
  • Reusable templates to locate the holdown anchor bolts accurately for multiple footing types
  • Top-of-wall shear transfer accomplished with a single plate that is fastened with a combination of Strong-Wall screws and heavy-duty connector screws
  • Suitable for residential, multifamily and light-frame commercial construction
  • Evaluated to the 2018 IRC/IBC and listed by ICC-ES
  • Vertical panel made from laminated strand lumber
  • Top-of-wall connection plates are galvanized G90

Features

  • Reusable templates to locate the holdown anchor bolts accurately for multiple footing types
  • Top-of-wall shear transfer accomplished with a single plate that is fastened with a combination of Strong-Wall screws and heavy-duty connector screws
  • Suitable for residential, multifamily and light-frame commercial construction
  • Evaluated to the 2018 IRC/IBC and listed by ICC-ES
  • Vertical panel made from laminated strand lumber
  • Top-of-wall connection plates are galvanized G90

Specifications


MaterialLaminated strand lumberConnection plate finishGalvanized G90
*
*
*
