Spectra Precision DG613 Pipe Laser Package

Mfr.: Spectra Precision
Item #: I090622
Mfr. #: DG613-13
*
Pickup at Buena Park | Change Delivering to 92111 | Change

Price: $6,973.80
i h h

Description

The DG613 is a compact and powerful pipe laser designed to fit into tight inverts in manholes while delivering high productivity. It features an extensive grade range from -12% to +40% and is fully self-leveling across the entire range, including cross-axis compensation. Equipped with advanced functions like Line Set/Check and Line Alert, this laser ensures quick, accurate setups and alerts the user if the setup line is disturbed.

Features

  • Grade range of -12% to +40% with full self-leveling and cross-axis compensation.
  • Compact length allows for easy setup even in the tightest manhole inverts.
  • Operating range up to 150 meters (500 feet) for full operation in a single setup between manholes.
  • Line Alert feature notifies users if the setup has been disturbed to eliminate rework.
  • IP68 rated protection ensures the device is completely dust and waterproof.
Products specifications
Self-Leveling Range Longitudinal: Over the entire grade range with au
Accuracy +/- 1.5 mm/30 m, (1/16 in @ 100 ft) 10 arc second
Laser Type Class 3A/3R, <5mW OR Class 2
Power Source Life 10000mAh NiMH battery pack; Red beam: 40 hours
Grade Range -12% to +40%
Operating Range Up to 150 m (500 feet)
Storage Temperature -20 degC to 70 degC (-4 degF to 158 degF)
Operating Temperature -20 degC to 50 degC (-4 degF to 122 degF)
Dust Waterproof Yes (IP68/IP67)
Weight 3.98 kg (6.61 lbs)
Tripod Mount 5/8 x 11 horizontal
Warranty 5 Years
*
*
*
