WR Meadows Sponge Rubber Expansion Joint - 1/4" X 36" X 10'

Mfr.: WR Meadows
Item #: I101124
Mfr. #: 2101361100
*
Pickup at Buena Park | Change Delivering to 92111 | Change

Price: Call for pricing
i h h

Description

Compressible, resilient joint filler for concrete expansion and contraction. Made from blown sponge rubber, it compresses easily and recovers most of its original thickness after movement.
  • High resiliency with excellent recovery after compression
  • Easy to handle and install
  • Offers isolation capabilities

Features

  • High resiliency with excellent recovery after compression
  • Easy to handle and install
  • Offers isolation capabilities

Specifications


Thickness1/4 inch (6.35 mm)Width36 inch (914.4 mm)
Length10 (3.05 m)Density30 lb./ft3 (480 kg/m3)
Compression Force Deflection (50% Compression)50 psi (0.3 MPa)Recovery (Compressed 50% at RT for 10 min)90%
Extrusion (Compressed 50% with 3 edges restrained0.250 inch (6.4 mm)Temperature Range-20 degF to 160 degF (-84 degC to 71 degC)
StandardsAASHTO M 153 Type 1, ASTM D1752 Type 1, Corps of E
*
*
*
